By Diamond Audio

6"x9" 2-Way Coaxial Speaker w/Titanium Dome Tweeter (2Ω) - MS692CX2

$329.99
$439.99 $329.99
-25%
Brand: Diamond Audio
SKU: MS692CX2

Bass That Bites Back

Forget weak outdoor audio. This extreme-duty series packs a massive punch, delivering rich, thumping lows and razor-sharp vocals that effortlessly slice through wind, waves, and engine roar.

Armored for Adventure

Rain, mud, or saltwater—nothing stops your playlist. Built with heavy-duty marine-grade armor, these high-output components guarantee an ultra-premium, full-range acoustic experience in any extreme environment.

6"x9" 2-Way Coaxial Subwoofer w/Titanium Dome Tweeter (2Ω)

Turn it up and let it roar—the Diamond Audio MS692CX2 6"x9" 2-way coaxial Coax-Sub speakers (2Ω) are built to deliver explosive output, deep bass, and crystal-clear highs in the toughest environments. Designed for marine audio, motorcycles, UTVs, and powersports systems, this 2-ohm version is engineered for maximum amplifier efficiency and louder, more aggressive performance. Simply put—this speaker bangs.

Built to IPx65 marine-grade standards, the MS692CX2 is ready for water, salt, sun, and dust. The UV-treated waterproof Kevlar cone with rubber surround delivers tight, punchy mid-bass and enhanced durability, making it perfect for open-air and high-vibration environments.

The standout feature is its Coax-Sub design, giving you extended low-frequency response without needing a dedicated subwoofer. With a frequency response of 46Hz–20kHz and 130W RMS / 500W MAX power handling, this 6x9 coaxial speaker produces rich, full-bodied sound that hits hard while staying clean and controlled.

Up top, the 1" high-output titanium dome tweeter delivers sharp, detailed highs that slice through wind and engine noise. The integrated 12dB Bessel crossover network ensures smooth transitions between frequencies, creating a balanced and dynamic listening experience.

The 2-ohm impedance allows your amplifier to push more power, resulting in higher output and improved system performance. Combined with a super high-energy ferrite motor system and milled aluminum top plate, the MS692CX2 delivers serious output with excellent control.

A T-yoke back plate design improves cooling by 35%, while the cast aluminum basket ensures long-term durability in harsh conditions.

Key Features

• Model: MS692CX2 (2Ω Coax-Sub Design)
• 6"x9" 2-way marine coaxial speakers (2Ω)
• 125W RMS / 500W MAX power handling
• 1" titanium dome tweeter for crisp highs
• Kevlar waterproof cone with rubber surround
• IPx65 marine-grade compliant construction
• Enhanced low-frequency “Coax-Sub” performance
• High-efficiency 2-ohm design for louder output
• Fully waterproof cone and surround for marine environments

The Diamond Audio MS692CX2 Coax-Sub speakers deliver aggressive, full-range sound with serious punch—built for riders and adventurers who want maximum volume, deep bass, and unstoppable performance on every ride.



Specifications

  • Power Handling Watts (RMS/Peak): 130W/520W
  • Nominal Impedance (Ω): 2Ω
  • Frequency Response (Hz): 45Hz-23kHz
  • Voice Coil: 1.66" (42.2mm)
  • Fs - Free Air Resonance (Hz): 46Hz
  • Qts: 0.51
  • Vas ft³ (Liter): 0.794" (22.5L)
  • Sensitivity (1W/1M): 87.6db
  • Sensitivity( 2.83V/1M): 94.6db
  • Xmax (mm): 0.315" (8mm)
  • Mounting Depth: 3.818” (97mm)
  • Mounting Diameter: 5.98”x8.85” (152mmX225mm)

Specifications

  • Nominal-impedance-ohms

    2Ω

Brand

Diamond audio

Type

Motor vehicle speakers
