By Diamond Audio

10" Motorsports Series Marine Subwoofer w/LED Grill - MS104SL

$259.99
$259.99
Brand: Diamond Audio
SKU: MS104SL

Rugged Marine-Grade Protection

Protect your investment with this UV-resistant, factory-fit grill series, engineered to deliver long-lasting durability and a professional, seamless finish in the harshest outdoor environments.

Dynamic LED Visual Upgrade

Ignite your deck with integrated lighting and a sleek design that provides a high-value, easy-to-install style boost, ensuring your marine sound system stands out all night.

10" Marine Subwoofer with Grill

Upgrade your marine or powersports audio system with the Diamond Audio MS104SL 10" Motorsports Series marine subwoofer, engineered for powerful bass, rugged durability, and eye-catching LED styling. Designed to deliver high-output performance in demanding environments, this subwoofer is the perfect addition to boats, UTVs, and outdoor audio systems.

Built to IP65 marine grade compliance, the MS104SL is constructed using UV-treated ASA high-impact thermoplastic, making it resistant to sun exposure, salt, and water. This rugged design ensures long-lasting performance in harsh marine and off-road conditions, while the durable grill provides added protection.

With 200W RMS / 400W MAX power handling, this 10-inch marine subwoofer delivers deep, punchy bass with excellent clarity and control. The high-excursion design (12.3mm Xmax) allows for greater low-frequency output, while optimized Thiele/Small parameters ensure tight, accurate bass response across a wide range of music styles.

The MS104SL features a waterproof polypropylene cone paired with a super high-energy neodymium motor structure, providing enhanced efficiency and reliable performance. With an 87dB sensitivity rating and 32.94Hz Fs, this subwoofer produces strong low-end extension and dynamic output, even in open-air environments.

Included is a white LED grill with integrated RGB lighting, adding a customizable visual element to your system. Optional controllers (DARGB8A or HXMRGBLC) allow you to tailor lighting effects to match your environment or mood. A black grill option (MS10GRLB) is also available for alternative styling.

Designed for versatility, the MS104SL fits a wide range of installations with a 9.22" mounting diameter and 4.74" mounting depth, making it suitable for various marine and powersports applications.

Key Features

• Model: MS104SL – Motorsports Series Marine Subwoofer
• 10" marine subwoofer with LED grill
• 200W RMS / 400W MAX power handling
• IP65 marine grade compliant construction
• 12.3mm Xmax for deep, powerful bass
• Waterproof polypropylene cone with neo motor
• Integrated RGB LED lighting (controller sold separately)
• Fully waterproof cone and surround for marine environments

The Diamond Audio MS104SL delivers deep bass, durable construction, and customizable style, making it the ultimate marine subwoofer for high-performance outdoor audio systems.



Specifications

  • Power: 200W RMS/400W MAX
  • SPL(dB): 87
  • Re(Ω)[Series]: 3.3
  • Qms: 2.837
  • Qes: 0.491
  • Qts: 0.419
  • Fs(Hz): 32.94
  • Vas(L): 45.2
  • Cms(mm/N): .0241
  • Mms(g): 96.674
  • Sd(m²): 0.036
  • BL(T*M): 11.591
  • Xmax (mm) : 12.3
  • Included: White Grill with LED
  • LED Controller Sold Separately: DARGB8A or HXMRGBLC
  • Black Grill sold separately: MS10GRLB
  • Mounting Diameter: 9.22” / 234.3mm
  • Mouthing Depth: 4.74” / 120.3mm
  • Outside Diameter: 10.91” / 277.0mm

Sealed Enclosure:

  • Vb(ft³): 0.75
  • F3 (Hz)/QTC: 59/.73
  • Pe(W): 200

Vented Enclosure:

  • Vb(ft³): 1.75
  • F3 (Hz)/QTC: 59/.73
  • Port (Dia. x Length): 3"x8.5"
  • Pe(W): 200

Specifications

  • Nominal-impedance-ohms

    4Ω

Brand

Diamond audio

Type

Subwoofer
